What is Touring LED?
Touring LED — also called rental LED — is designed for repeated setup and packdown. The panels use lightweight frames (typically magnesium alloy) with fast-lock connections so a crew can build a large video wall in an hour and strike it just as quickly.
Touring panels are built to take punishment. They get loaded into flight cases, driven across the country, rigged on trusses, and exposed to varying environmental conditions — night after night, event after event. Every component is designed with that abuse in mind: recessed connectors, protective corner guards, and a pixel pitch in the P2.6–P3.9mm range that gives a solid image at typical stage viewing distances without being fragile.
The Leyard LN Series and LN-VP Series are purpose-built touring panels — front-serviceable, IP65-rated, and designed for ground stacking or overhead rigging on truss systems.
What is Install LED?
Install LED is designed to go up once and stay there. Permanent installations prioritise image quality, seamless tiling, and long-term reliability over setup speed. Cabinet engineering focuses on even heat dissipation, minimal seam visibility, and clean integration with the architecture around it.
Because it doesn't need to be portable, install hardware can be more substantial — deeper cabinets, heavier frames, and rear service access (where a wall recess or maintenance corridor allows). The pixel pitch range is also broader: from ultra-fine P0.9mm for control rooms and broadcast studios down to P4mm for larger lobbies or conference halls.
The Leyard TXF and TXC Series represent the premium end of install LED — ultra-narrow pixels, precision calibration, and a build quality suited to high-profile permanent environments.
The Core Principle
Touring LED is optimised for repetition. Install LED is optimised for permanence.
You can technically use touring panels as a permanent install — and sometimes that's the right call for budget or flexibility reasons — but you're trading long-term image quality and thermal performance for portability you won't use.
Feature Comparison
| Factor | Touring / Rental | Permanent Install |
|---|---|---|
| Panel construction | Lightweight magnesium alloy frames | Steel/aluminium cabinets, heavier |
| Setup time | Minutes — snap-lock connections | Hours or days — engineered mounting |
| Pixel pitch typical | P2.6mm – P3.9mm | P0.9mm – P4mm (full range) |
| Service access | Front-serviceable essential | Front or rear depending on install |
| Rigging | Designed for truss and ground stacks | Wall, ceiling, or custom structure |
| Brightness | 1,500–5,000 nits (indoor/outdoor mix) | 800–3,000 nits (environment-dependent) |
| IP rating | IP65 rated panels common | IP20–IP65 depending on location |
| Typical lifespan approach | 10+ years, high-use cycles | 10–15+ years, consistent environment |
| Cost per sqm | Mid-range — mass-produced rental format | Varies — finer pitch commands premium |
Choosing the Right Approach
Use touring panels when...
Your screen moves between locations — concerts, festivals, conferences, exhibitions, or temporary activations. Also valid when you want flexibility to reconfigure size and shape between events.
Use install panels when...
Your screen is permanent or near-permanent — corporate lobbies, boardrooms, retail environments, control rooms, broadcast studios, or outdoor signage that stays in place.
The hybrid scenario
Some clients install touring-grade panels permanently because they want the option to loan or redeploy screens in the future. This works, but factor in that touring panels aren't optimised for 24/7 operation cycles.
When you own a rental fleet
Purpose-built rental inventory (LN, LN-VP) is worth the investment. Panels that are designed to be shipped, rigged, and recovered will outlast repurposed install hardware in this role.
Leyard Series Reference
Touring / Rental
- LN Series — lightweight touring, P2.6–3.9mm
- LN-VP Series — ultra-light variable pixel pitch
- VHR Series — fine pitch rental, P1.5–P2.5mm
- LV Series — outdoor rental, P3.9–P6.25mm
Permanent Install
- TXF Series — ultra-fine pitch, P0.9–P1.5mm
- TXC Series — fine pitch indoor, P1.5–P2.5mm
- MG-2 Series — mid-range indoor install
- HKS II — commercial display, P1.5–P2.5mm
- LA Series — outdoor permanent, P4–P10mm
