Overview
The VHR Series offers fine pixel pitch in a rental-ready form factor — with dedicated VHRI indoor models and VHRO outdoor models. Indoor pitches from P1.56mm suit broadcast-quality events and presentations; outdoor VHRO variants reach 5,000 nits for fully lit outdoor environments. One-piece die-cast cabinets, 45° cut corners for flexible splicing, and full front dismantling make the VHR one of the most versatile fine-pitch rental products available.
Available Models
VHRI1.5
P1.5625mm (indoor)
VHRI1.9
P1.95mm (indoor)
VHRI2.5
P2.5mm (indoor)
VHRI2.9
P2.97mm (indoor)
VHRI3.9
P3.91mm (indoor)
VHRO1.5
P1.5625mm (outdoor)
VHRO1.9
P1.95mm (outdoor)
VHRO2.5
P2.5mm (outdoor)
VHRO2.9
P2.97mm (outdoor)
VHRO3.9
P3.91mm (outdoor)
VHRO4.8
P4.84mm (outdoor)
Applications
- Stage shows, concerts, and festivals
- Corporate conferences and product launches
- Celebrations, awards nights, and gala events
- Exhibition and trade shows
- Outdoor events and semi-outdoor venues
- Sports events requiring fine detail
Key Features
Separate indoor (VHRI) and outdoor (VHRO) variants in a common form factor
VHRO outdoor models: up to 5,000 nits at P3.91mm and P4.84mm
3,840Hz high refresh — broadcast and camera-safe across all models
One-piece die-cast cabinet — durable, wear-resistant, anti-oxidation
45° cut corners with flexible module splicing
Full front dismantling and assembly for on-site service
Curvable — concave and convex configurations supported
HDR10 with grey level enhancement
Black screen energy-saving mode
Signal loop backup technology built in
Product Gallery
Technical Specifications
| Pixel Pitch (Indoor VHRI) | P1.5625mm – P3.91mm |
| Pixel Pitch (Outdoor VHRO) | P1.5625mm – P4.84mm |
| LED Type | SMD |
| Indoor Brightness (VHRI) | 800 nits |
| Outdoor Brightness (VHRO) | 3,000–5,000 nits (pitch dependent) |
| Refresh Rate | 3,840Hz |
| Contrast Ratio | 5,000:1 |
| Viewing Angle (H/V) | 160° / 140° |
| Max Power Consumption | 580–600 W/m² |
| Stacking / Hanging | Both supported |
| Indoor Operating Temp | −20°C to +40°C |
| Outdoor Operating Temp | −30°C to +50°C (VHRO2.5 and above) |
| Operating Humidity | 10–80% RH |
| Lifespan | 100,000+ hours |
Specifications subject to change. Consult LUX for final configuration details applicable to your project.
