COB Fine Pitch Indoor
MG-2 COB
SERIES
COB Technology — IP65, High Contrast, Essential and Ultra Tiers
Overview
The MG-2 COB Series uses full flip-chip COB packaging — LED chips bonded directly onto the PCB — delivering a flat, smooth surface rated IP65. With no exposed LED packages to break or oxidise, it's significantly more durable than conventional SMD displays in high-traffic or harsh-cleaning environments. Available in Essential and Ultra performance tiers, the Ultra variant achieves 30,000:1 native contrast for deep blacks even in ambient light. Cabinet thickness is just 39.9mm.
Available Models
MG0078-2COB Ultra
P0.78mm
1,638,400 px/m²
MG0093-2COB Essential
P0.9375mm
1,137,778 px/m²
MG0093-2COB Ultra
P0.9375mm
1,137,778 px/m²
MG0125-2COB Essential
P1.25mm
640,000 px/m²
MG0125-2COB Ultra
P1.25mm
640,000 px/m²
MG0156-2COB Essential
P1.5625mm
409,600 px/m²
MG0156-2COB Ultra
P1.5625mm
409,600 px/m²
Applications
- Interactive museum and exhibition displays
- High-traffic retail environments requiring durable surfaces
- Corporate environments with high ambient light
- Healthcare facilities — easy-clean IP65 surface
- Education and collaborative spaces
- Environments requiring touchscreen integration
Key Features
Full Flip Chip COB packaging — IP65 rated, no exposed LED packages
Ultra variant: 30,000:1 contrast ratio — exceptional black levels
Flat, smooth front surface rated for regular cleaning
Only 39.9mm cabinet depth — ultra-slim profile
Essential tier (800–1,500 nits) and Ultra tier (1,000–2,000 nits)
16-bit greyscale for superior shadow detail
Front and rear installation with front-access maintenance
Floating connectors for precision alignment and reliable connection
HDR / 10-bit colour depth
Product Gallery
Technical Specifications
| Pixel Pitch Range | P0.78mm – P1.5625mm |
| LED Technology | Full Flip Chip COB |
| IP Rating | IP65 |
| Contrast Ratio | 25,000:1 (Essential) / 30,000:1 (Ultra) |
| Brightness | 500–1,500 nits (Essential) / 600–2,000 nits (Ultra) |
| Refresh Rate | 1,600–3,840Hz (Essential) / 3,840Hz (Ultra) |
| Greyscale | 16-bit |
| Cabinet Size (W×H×D) | 600 × 337.5 × 39.9mm |
| Cabinet Weight | ~4.5 kg |
| Lifespan | 100,000 hours |
| Operating Temperature | −10°C to +40°C |
| Operating Humidity | 10–80% (no condensation) |
Specifications subject to change. Consult LUX for final configuration details applicable to your project.
