Ultra Fine Pitch Indoor
TXF
SERIES
Micro LED & COB — Front-Access Ultra Fine Pitch Indoor
Overview
The TXF Series brings Leyard's Micro LED and RGB COB technology to a front-maintenance cabinet engineered to cover 80% of indoor requirements. Using RGB full flip-chip packaging under 100 microns, the TXF achieves pixel pitches down to P0.78mm — enabling 4K UHD at remarkably small screen sizes. Common cathode drive technology cuts total power consumption by up to 50% versus conventional designs, while contrast ratios reach 30,000:1 on the COB variant.
Available Models
TXF0078
P0.78mm
1,638,400 px/m²
TXF0093 Micro LED
P0.9375mm
1,137,778 px/m²
TXF0093 RGB COB
P0.9375mm
1,137,778 px/m²
TXF0125 Micro LED
P1.25mm
640,000 px/m²
TXF0125 RGB COB
P1.25mm
640,000 px/m²
TXF0156
P1.5625mm
409,600 px/m²
TXF0187
P1.875mm
284,444 px/m²
Applications
- Broadcast studios and live television production
- Design centres and creative agencies
- Control centres requiring pixel-precise imagery
- Executive boardrooms and C-suite environments
- Conference rooms and presentation suites
- Exhibition centres and museum installations
- Home cinema and premium residential
Key Features
RGB full flip-chip Micro LED technology — nanoscale chips under 100 microns
Common cathode drive mode — up to 50% lower energy consumption
Contrast ratio up to 30,000:1 on RGB COB variant
Peak brightness up to 2,000 nits across Micro LED models
100% DCI-P3 colour gamut with pixel-by-pixel calibration
3,840Hz refresh rate — flicker-free in broadcast and camera environments
10-bit colour depth with HDR support
Front access maintenance — module swap without rear access
Covers P0.78mm through P1.875mm — 80% of all indoor use cases
Product Gallery
Technical Specifications
| Pixel Pitch Range | P0.78mm – P1.875mm |
| LED Technology | Micro LED (RGB Full Flip Chip) / RGB COB |
| Drive Mode | Common cathode constant current |
| Peak Brightness | ≥1,200–2,000 nits (model dependent) |
| White Balance Brightness | 800–1,200 nits |
| Contrast Ratio | ≥10,000:1 (Micro LED) / ≥30,000:1 (COB) |
| Refresh Rate | 3,840Hz |
| Greyscale | 25-bit (16+9) |
| Colour Temperature | 3,000K – 10,000K adjustable |
| Brightness Uniformity | ≥97% |
| Viewing Angle (H/V) | 170° / 150° – 170° |
| Cabinet Size (W×H×D) | 600 × 337.5 × 67mm |
| Surface Flatness | ≤0.1mm |
| IP Rating | IP30 (front) |
| Operating Temperature | −10°C to +40°C |
| Operating Humidity | 10–80% (no condensation) |
| Lifespan | 100,000+ hours |
Specifications subject to change. Consult LUX for final configuration details applicable to your project.
